CDM-840 Remote Router Revision 2
Ethernet-based Remote Product Management MN-CDM840
6–8
6.4.2.5 Drop-down Lists
A drop-down list lets you choose from a list of
selections. Left-click the drop-down button to open
the list. Then, left-click on an item to select that
choice.
6.4.2.6 Text or Data Entry
Text boxes let you type data into a field. An action button may
be associated with a single text box, or a group of text boxes.
For any text box, left-click anywhere inside the box, type the
desired information into that field, and be sure to press
[ENTER] when done.
Click the related action button to save the data.
If you edit any field, make sure to click the action button before you leave the
page. If you go to another page without first clicking the ac
tion button, your
changes are not saved.
