CDM-840 Remote Router Revision 2
Ethernet-based Remote Product Management MN-CDM840
6–63
Ethernet Statistics
From left to right:
Column
Description
Total Pkts Xmitted
Total number of packets transmitted.
Total Pkts Rcvd
Total number of packets received.
UC Pkts Xmitted
Unicast packets transmitted.
UC Pkts Rcvd
Unicast packets received.
MC Pkts Xmitted
Multicast packets transmitted.
MC Pkts Rcvd
Multicast packets received.
Current Xmitted (kbps)
Most recent transmitted data rate (in kilobits per second).
Current Rcvd (kbps)
Most recently received data rate (in kilobits per second).
Maximum Xmitted (kbps)
Peak transmitted data rate (in kilobits per second).
Maximum Rcvd (kbps)
Peak received data rate (in kilobits per second).
Mod Statistics
From left to right:
Column
Description
Pkts Xmitted
Packets transmitted.
UC Pkts Xmitted
Unicast packets transmitted.
MC Pkts Xmitted
Multicast packets transmitted.
Pkts Dropped
Packets dropped.
UC Pkts Dropped
Unicast packets dropped.
MC Pkts Dropped
Multicast packets dropped.
Current (kbps)
Most recent symbol rate (in kilobits per second).
Maximum (kbps)
Peak symbol rate (in kilobits per second).
Total Bytes Xmitted
Total number of bytes transmitted.
Demod Statistics
From left to right:
Column
Description
Pkts Rcvd
Packets received.
UC Pkts Rcvd
Unicast packets received.
MC Pkts Rcvd
Multicast packets received.
Pkts Dropped
Packets dropped.
UC Pkts Dropped
Unicast packets dropped.
MC Pkts Dropped
Multicast packets dropped.
Cur Rate (kbps)
Most recent symbol rate (in kilobits per second).
Max Rate (kbps)
Peak symbol rate (in kilobits per second).
