CDM-840 Remote Router Revision 2
Ethernet-based Remote Product Management MN-CDM840
6–6
Step
Task
1
On the Tools menu, click Internet Options.
2
On the General tabbed page:
Under Browsing history, click [Settings].
3
On the Temporary Internet Files and History Settings page:
Under Check for Newer Versions of Stored Pages:, click Every Time I visit the webpage.
4
Click [OK] to save the selection and close the Temporary Internet Files and History Settings page.
5
Click [OK] to close the Internet Options page.
6
Restart your browser.
The Enhanced Mode virtual LEDs indicate the active operating state of the unit as follows:
LED
Condition
UNIT STATUS
Green
No Unit Faults or Alarms.
Amber No Unit Faults, but an Alarm exists.
Red
A Unit Fault exists (Example: PSU fault).
STORED EVENT
Amber
There is a Stored Event in the log, which can be viewed from the Web Server
Interface
Off
There are no Stored Events.
ONLINE
Green
The Unit is On Line, and carrying traffic.
Off
The Unit is Off Line (standby) – forced by externally connected 1:1 or 1:N
redundancy system.
TEST MODE
Amber
A Test Mode is selected
Off There is no Test Mode currently selected.
TRANSMITTER
ON
Green
The Transmitter Carrier is On.
Red
A Fault exists that causes the unit to turn off the carrier.
Off The Transmitter Carrier is
Off.
Tx TRAFFIC
Green (solid)
No Tx Traffic Faults, no packets.
Green (blinking)
No Tx Traffic Faults, blinks when a packet is being transmitted to the satellite link
from this unit.
Amber
A Tx Traffic Alarm exists.
Red
Tx Traffic has a Fault.
Off
A Tx Traffic Fault exists.
Rx TRAFFIC
Green (solid)
No Rx Traffic Faults (demod and decoder are locked, everything is OK).
Green (blinking)
No Rx Traffic Faults, blinks when a packet is being received from the satellite link
to this unit.
Amber
Rx Traffic has an Alarm.
Red
Rx Traffic has a Fault.
Off An Rx Traffic fault exists (the demod may still be OK).
GE
LINK/ACTIVITY
Green (solid)
Traffic Ethernet is connected, but no traffic exists.
Green (blinking)
Ethernet activity detected.
Off
Traffic Ethernet is not connected.
