CDM-710 Broadcast Satellite Modem Revision 11
Installation MN/CDM710.IOM
2–4
2.2.2 Method B: Optional Bearingless Side-Railings
Figure 2-2 depicts rack-mounting via use of the optional CEFD P/N FP/SL0006 Bearingless
Side-Railings, installed using user-furnished standard shop tooling and mounting hardware:
Optional Bearingless Side-Railings (CEFD P/N FP/SL0006)
Quantity CEFD Part Number Description
2 FP/SL0006 Bearingless Side-Railing
Figure 2-2. Installation of Optional Bearingless Side-Railings (FP/SL0006)
