UT-4500A Series Upconverters Revision 0

Introduction MN-UT4500A

1–17

Characteristic Specification

Test Points

(Front Panel)

RF Sample Type ‘SMA’ Connector, -20 dBc Nominal

IF Sample Type ‘BNC’ Connector, -20 dBc Nominal

Power Voltage 90-250 VAC Autoranging

Frequency 47-63 Hz

Dissipation 60 Watts

Environmental Temperature 0-50°C (32-122° F)

Altitude 10,000 Feet MSL

Humidity 0-95% Relative

Physical Width 19 Inches (48.26 cm)

Height 1RU 1.75 Inches (4.44 cm)

Depth 22 Inches (55.88 cm)

Weight 15 Pounds (7.00 kg)

Options -1 IO Module

-2 RF/IF Switch

Summary Alarm Relay Closure Form C
