CRS-100 1:1 Redundancy Switch Revision 2

\Physical Description MN/CRS100.IOM

MN/CRS100.IOM 3–3

3.4 Side Panel - Left Side

On the side panel (Figure 3-1) to the left are the two Receive IF ports, ‘A’ and ‘B’, which

are both BNC female. Connection is made to the pair of Modems using Comtech EF Data

P/N CA/BNC 75 OHM ( 75 Ωapplications) or Comtech EF Data P/N CA/BNC 50 OHM

( 50 Ω applications).

Additionally, a small opening near the rear of the unit provides access to two switches,

which determine the conditions dictating an automatic switchover. This is described in

detail in Chapter 7.
