DMD2050E Universal Satellite Modem User Interfaces
MN-DMD2050E Revision 2 4–9
4.4.1.5 REED-SOLOMON (menu)
IMPORTANT
When Reed-Solomon is selected, these parameters are available.
ENABLE/DISABLE
{ENABLED, DISABLE} Enable or disable the Reed-Solomon Encoder.
RS RATE
{Refer to Table 3-1 for valid
n/k values}
Displays the currently used n, k Reed-Solomon Codes. In
Closed Net Mode, you can select custom R-S Codes.
INTERLVR DEPTH
{4, 8, 12} Select the Reed-Solomon interleaver depth. In Closed Net
Mode, you can select a depth of 4 or 8.
4.4.1.6 AUPC (menu)
IMPORTANT
AUPC Menus are available only when these conditions are true:
• The modulator is in Closed Net Network Spec
• Framing is set to EFAUPC or IBS 1/15
• Or the modulator is in EBEM mode and ITA is not enabled
