KP-10 External Keypad Revision 1
Operation MN/KP10.IOM
A–4
Figure 10 CA/6158
1
APPLY PART NUMBER AND REVISION TO LABEL
IN .12 HIGH CHARACTERS, COLOR BLACK,
USING PERMANENT INK, LOCATE
APPROXIMATELY WHERE SHOWN.
STRIP AND/OR TIN WIRES AS REQUIRED FOR
INSTALLING TERMINALS OR CONNECTORS
USING MANUFACTURERS INSTALLATION
PROCEDURE.
WIRE LIST
-RX
FROM
P1-1 P2-A
TO SIGNAL
P1-2 P2-D +RX
P1-3 P2-C +TX
P1-4
N/C -
P1-5 P2-J GND
P1-6 P2-B -TX
P1-7
N/C -
P1-8
N/C -
P1-9 P2-L +12V
PART NO.
CA/6158
DIM A
72.00 %%P3.00
CA/6158-1
132FT %%P4FT
TABLE A
OF .25 INCH OF HEAT SHRINK, ITEM 7, OVER
EACH SOLDER JOINT. SEE DETAIL A.
ALL WIRE TERMINATIONS SHALL HAVE A MINIMUM
"D" CONNECTOR TERMINATIONS
DETAIL
3
REPLACE SCREWS PROVIDED WITH HOOD,
ITEM 3, WITH SOCKET HEAD SCREWS, ITEM 8.
USE HEAT SHRINK, ITEM 5, TO BUILD UP CABLE
DIAMETER SO THAT CLAMP OF P2, ITEM 1,
CLAMPS TIGHTLY AROUND CABLE.
(P1)
(P2)
THE WRITTEN AUTHORIZATION OF EFDATA CORPORATION.
BE REPRODUCED, USED OR DISCLOSED TO OTHERS WITHOUT
DOCUMENT NOR THE I NFORMATION CONTAINED HEREIN SHALL
PROPRIETARY DATA OF EFDATA CORPORATION. NEITHER THIS
THIS DOCUMENT AND THE INFORMATION DISCLOSED HEREIN ARE
EFDATA PROPRIETARY
UNLESS OTHERWISE SPECIFIED
ALL DIMENSIONS ARE IN INCHES
ANGLE %%P
DO NOT SCALE DRAWING
FLATNESS .005 INCH PER INCH.
REMOVE BURRS AND SHARP
AND ARE AFTER COATING
SURFACE TEXTURE:
EDGES
TOL:
.
.XXX %%P
.XX %%p
125
.
APVD
APVD
CHK
FINISH
DFTG
MATERIAL
NEXT ASSY
APPLICATION
USED ON
C
SCALE
SIZE
4J515
CAGE CODE DRAWING NO.
SHEET 1
OF
REV.
NOTES: UNLESS OTHERWISE SPECIFIED
3
2X
2X
CA/6158
2
3
8
4
1
6
7
4
55
1
5
4
2
1
