SNM-1000 Node Control Modem Revision 3
Operation MN/SNM1000.IOM
3–40
3.4.5.5.2 SYSTEM:REMOTE BAUD RATE
REMOTE BAUD RATE
19.200 BPS NONE
The parity and baud rate settings of the modem are displayed.
To change the modem parity, press [ENTER].
• Press [←] or [→] to position the cursor over the parameter to be changed.
• Press [↑] or [↓] to change the parameter.
• Once the parameters are displayed as desired, press [ENTER] to set the baud rate
and parity.
• The parity can be set to EVEN, ODD, or NONE
.
The baud rate is 19200 bit/s.
3.4.5.5.3 SYSTEM:REMOTE ADDRESS
REMOTE ADDRESS
1
The current modem address is displayed (1 to 255).
Note: 0 is reserved as a global address.
To change the remote address, press [ENTER]. Press [↑] or [↓] to make the selection. Press
[ENTER] to execute the change.
3.4.5.5.4 SYSTEM:REMOTE TYPE
REMOTE TYPE
RS485 (2-WIRE)
Select RS-485 (2-Wire),
RS-485 (4-Wire), or RS-232.
