Ku-Band Satellite Transceiver Revision 9

Operation MN/KST2000AB.IOM

5–10

5.3.3 Faults

The SELECT: FAULTS menu is accessible from the SELECT menu (

Figure 5-7). Upon

entry, from the Select Menu, a Select Sub-level menu is displayed (Figure 5-8) allowing

access to several categories of faults.

The "*" indicator surrounding the *SELECT* display indicates the user is in the

FAULTS sub menu.

Press the [

W ] or [X] keys to select the desired fault category. Pressing [Enter] will enter

the indicated faults category and display the current status "OK" or "FLT" for the

displayed KST-2000A/B system. Pressing any arrow key will display the next monitored

system. Pressing the [Clear] key once will return the user to the faults menu, while

pressing the [Clear] key twice will return the user to the main SELECT menu.

Note: The upper level SELECT menu indicates "-SELECT-" while the faults menu

indicates "*SELECT*". This is done to distinguish the upper level select from the faults

level select menus.

Figure 5-7. Faults Menu Figure 5-8. Faults Sub-Level
