Hub Overview

Comtech EF Data Proprietary & Confidential 7

Sub-System Function

CDM-800 Gateway Router Transmits high-speed DVB-

S2 outbound

CDD-880 Multi-Receiver Router Multi-receiver for VersaFEC

return channel

CXU-810 RAN Optimizer E1 aggregation and RAN

optimization

Memotec CX-U 1240/1280 RAN optimization

CTOG-250 Traffic Optimization

Gateway & Protocol Server

Advanced Quality of Service

(QoS), Header & payload

compression, ACM/VCM

controller

Stampede FX-4000 WAN optimization &

application acceleration

Network Management System Network management

Vipersat dSCPC Controller Dynamic bandwidth

management

CRS-170A/180 Redundancy Switches
